RK500 series rental led Screen

500mm x 500mm cabinet

RK500 Rental LED display


RK500 rental LED display, has beautiful, atmospheric, quickly replace LED modules, power supply, and receiving cards (replacement in 10 s), 10 times faster than conventional rental LED display cabinets, so it can reduce the failure rate during stage rental and use. Duration is loved by leasing customers.

RK500 is a code used by SZLEDWORLD’s rental series. Its dot pitch is from P2.604 to P4.81 for indoor and outdoor use, and it is suitable for 250mmx250mm LED module size.

It is widely used in Stage Performances, churches, weddings, anniversary celebrations, exhibitions, banquets, conferences, foundations, openings, promotions, and other activities, stage background construction, lighting and sound equipment, and special effects equipment rental places.

Features

  • Modular control box easy for changing power supply and receiving card;
  • Magnetic module design to realize quick front and back service;
  • Suitable for P2.976, P3.91, P4.81 outdoor;
  • Indoor P2.604, P2.976, P3.91, P4.81;
  • Location pins left and right for fast assembly;
  • Lightweight: 8kg/cabinet;
  • Thin cabinet: 85mm ;
  • Power connectors and ethernet connectors are easy to assemble and disassemble.


Modular control box Design

The power supply, receiving, and HUB board are centrally installed in the control box. When there is a problem with these parts, we can quickly replace the entire control box without using tools, so as to ensure the continuity of the LED display.

LED Module quick maintenance

  1. The module is directly adsorbed on the cabinet with magnets. When disassembling the module, the module is directly pulled out with a vacuum chuck, and the new module is adsorbed to the cabinet with magnets to achieve rapid replacement.
  2. In order to make the module firm and reliable after installation, we can use the mounting knobs to fix the module.

Curved locks

The cabinet uses high-precision surface joint curved locks. it has higher precision than traditional arc locks. and the arc adjustment range is from -10 degrees to +10 degrees.

IP65 waterproof

The power supply and the receiving card can be assembled on the door, which is more The rubber ring surrounds the periphery of the rear cover for waterproofing. The cabinet is made of aluminum for natural heat dissipation and no exhaust vents. The front and rear of the cabinet are both IP65 waterproof.

Hanging bar and back support

There are 2 installation structures are reserved on the cabinet. one is a hanging beam, and the other one is a back support installation. they are convenient for stage rental use.

  1. With the hanging beam, it can be installed on the truss.
  2. Reserved holes on the back of the cabinet. it connects with back support for stacking installation on the ground.

Rental led display installation locks

There are fast locks on the top and bottom and left and right of the cabinet. it’s for fast splicing and disassembling.

Anti-collision system

The rental led display has to install and disassemble the cabinets often. the lamps in the 4 corners are easily damaged. The RK500 series is designed with anti-collision mounting blocks in the 4 corners to protect the lamps.

RK500 outdoor rental LED Display Specifications

Pixel PitchP2.97P3.91P4.81
LED typeSMD1415SMD1921SMD1921
Pixel configuration3-in-1 SMD3 in 1 SMD3-in-1 SMD
Pixel density112,896 pixels/m265,536 pixels/m243,264 pixels/m2
Module dimension(W*H)250*250mm250mmx250mm250mmx250mm
Module resolution84*84dots64*64dots52*52dots
Drive Method1/21 scan1/16 scan1/13 scan
MaintenanceFront and backFront and backFront and back
Cabinet size (W*H)500*500mm500x500mm500x500mm
Cabinet depth85mm85mm85mm
Cabinet material Aluminum Aluminum Aluminum
Cabinet weight8kg/pcs8kg/pcs8kg/pcs
Brightness≥4000 cd/m2≥4000 cd/m2≥4000 cd/m2
Best Viewing Distance3m to 30m4m to 40m5m to 50m
Viewing Angle140 * 140140 * 140140 * 140
Grey Level14 Bit14 Bit14 Bit
Refresh Rate≥1920HZ≥1920HZ≥1920HZ
Power consumption(Avg.)70w/cabinet65w/cabinet60w/cabinet
Power consumption(Max.)200w/cabinet195w/cabinet190w/cabinet
Humidity-operating10% ~ 95%10% ~ 95%10% ~ 95%
Operating Temperature-20° – 50° C-20° – 50° C-20° – 50° C
Screen life≥100000 hours≥100000 hours≥100000 hours
Controlling SystemSync or AsyncSync or AsyncSync or Async
CertificatesCE,RoHS,FCC,ULCE,RoHS,FCC,ULCE,RoHS,FCC,UL
Ingress Protection (IP)IP65IP65IP65
Warranty3 Years3 Years3 Years
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to SZLEDWORLD.

RK500 Indoor rental LED Display Specifications

Pixel Pitch P2.604 P2.97 P3.91 P4.81
LED typeSMD2121/1515SMD2121SMD2121SMD2121
Pixel configuration3-in-1 SMD3-in-1 SMD3 in 1 SMD3-in-1 SMD
Pixel density147,456 pixels/m2112,896 pixels/m265,536 pixels/m243,264 pixels/m2
Module dimension(W*H)250*250mm250*250mm250*250mm250*250mm
Module resolution96*96dots84*84dots64*64dots52*52dots
Drive Method1/32 scan1/21 scan1/16 scan1/13 scan
MaintenanceFront and backFront and backFront and backFront and back
Cabinet size (W*H)500*500mm500*500mm500*500mm500*500mm
Cabinet depth85mm85mm85mm85mm
Cabinet material Aluminum Aluminum Aluminum Aluminum
Cabinet weight7.7kg/pcs7.7kg/pcs7.7kg/pcs7.7kg/pcs
Brightness≥1000 cd/m2≥1000 cd/m2≥1000 cd/m2≥1000 cd/m2
Best Viewing Distance2.5m to 25m3m to 30m4m to 40m5m to 50m
Viewing Angle140 * 140140 * 140140 * 140140 * 140
Grey Level14 Bit14 Bit14 Bit14 Bit
Refresh Rate≥1920HZ≥1920HZ≥1920HZ≥1920HZ
Power consumption(Avg.)60w/cabinet55w/cabinet50w/cabinet50w/cabinet
Power consumption(Max.)170w/cabinet160w/cabinet150w/cabinet150w/cabinet
Humidity-operating10% ~ 95%10% ~ 95%10% ~ 95%10% ~ 95%
Operating Temperature-20° – 50° C-20° – 50° C-20° – 50° C-20° – 50° C
Screen life≥100000 hours≥100000 hours≥100000 hours≥100000 hours
Controlling SystemSync or AsyncSync or AsyncSync or AsyncSync or Async
CertificatesCE,RoHS,FCC,ULCE,RoHS,FCC,ULCE,RoHS,FCC,ULCE,RoHS,FCC,UL
Ingress Protection (IP)IP31IP31IP31IP31
Warranty2 Years2 Years2 Years2 Years
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to SZLEDWORLD.

Video for P3.91 outdoor rental led screen

RK500 Rental LED Display

The 4 LED displays installed on the runway show are all RK500 series indoor stage rental LED displays, which can quickly replace LED modules, power supplies, and receiving cards within 10 seconds to ensure that the fashion show can be completed perfectly.

  • Pixel pitch: P3.91;
  • Middle LED Display size: W4pcs x H10pcs x 2 sets,total 80pcs cabinets;
  • Sides LED Display size: W10pcs x H6pcs x 2 sets,total 120pcs cabinets;
  • Cabinet size: 500mm x 500mm;
  • Maintenance : Front u0026amp; Back;
  • Cabinet Weight:7.7kg/pcs;
  • Location: France.
